FLNG Coral South Permanent Internal Turret




Scope of Work

SOFEC will design, construct, fabricate and install a permanent internal turret for the Eni Coral South FLNG.

The Coral South FLNG Turret represents SOFEC’s 4th Single Point Mooring System for LNG related business and using SOFEC’s High Integrity Pressure Protection Systems (HIPPS) technology. SOFEC’s design enables a reduced pressure envelope through the swivel stack by efficiently locating the HIPPS on the geostationary part of the turret. This results in increased operational safety on the FLNG vessel, thereby increasing safety for personnel. This technology also clears deck space on the vessel where real estate is at a premium.

FLNG Coral South Permanent Internal Turret Location Image



SOFEC will design, construct, fabricate and install a permanent internal turret for the Eni Coral South FLNG.

The Coral South FLNG Turret represents SOFEC’s 4th Single Point Mooring System for LNG related business and using SOFEC’s High Integrity Pressure Protection Systems (HIPPS) technology. SOFEC’s design enables a reduced pressure envelope through the swivel stack by efficiently locating the HIPPS on the geostationary part of the turret. This results in increased operational safety on the FLNG vessel, thereby increasing safety for personnel. This technology also clears deck space on the vessel where real estate is at a premium.

FLNG Coral South Permanent Internal Turret Location Image



General Description

Client Name:ENI
Contract Award:July 2017
Installation Date:Planned for 2022
First Oil:Planned for 2022
Vessel Size:210,000 mt
Process Capacity:3.4 MTPA LNG
Water Depth:2,000m (6,560 ft)
Fabrication:Turret - Vessel - MMHE



Design Environmental Criteria




100-year storm

Sig. Wave Height:7.4m (24ft)
Wind Velocity:27.5m/s (33 kts)
Current:1.09m/s (2.1 kts)



Fluid Swivel Assembly




(3) 12-in Toroidal Production Swivel
(1) 12-in Toroidal Fire Water Swivel
(1) 8-in Toroidal Pigging Swivel
(1) Low Voltage Electrical Slip Ring
(1) Low Voltage Electrical Optical Slip Ring




Riser System




(6) 12 inch Flexible Risers plus 2 future
(3) umbilcals plus 1 future


Download Spec Sheet
